Acrylic Variable Area Flowmeter KFR<br />
Marca: Kobold USA<br />
Modelo: KFR-45165-V1<br />
Accuracy: ±3% of Full Scale<br />
Range SCFM: 1...10<br />
Fittings: 1/4" NPT<br />
Body: Clear Acrylic<br />
Conexión material: Brass<br />
Float Material: SS<br />
[V1]: Options, Brass Inlet Needle Valve

Model: DPE-11-20-N8-G34R<br />
Pelton Wheel Flowmeter DPE<br />
[DPE-11]:<br />
Operating principle: Pelton Wheel (6-vane)<br />
Mounting position / flow direction: In all directions/ In direction of the arrow<br />
Protection: IP65<br />
Max. Temperatura: 80°C<br />
Max. Pressure: PN 40 (DPE-1200W: 16 bar)<br />
Accuracy of final value: +/-2,5%<br />
Material Housing: Brass casting<br />
Material Axis: Hard metal<br />
[20]: Measuring range, 25-250 L/min<br />
[N8]: Mech. Connection, 1 1/2" NPT female<br />
[G34R]: ZED-evaluating electronics, Dosing electronic, supply 24 VDC, 0(4)-20 mA, 2 SPDT

<strong>EP-P-309B-1-HH-2-0/UMF2-C-1-1-G-0BH-1<br />
Magnetic inductive flowmeter<br />
Brand: Kobold-Heinrichs</strong><br />
P: PTFE (PFA), standard 3 Hastelloy electrodes -20°C...150°C<br />
309B: <br />
DN25 PN40 Form B1 DIN EN 1092-1<br />
Max. measuring range (Water 20°C, 1 mPas), 17.6 m³/h<br />
1: Material flanges, steel (painted)<br />
HH: Material electrodes, Hastelloy C-4 incl. grounding electrode standard for PTFE<br />
1: Transmitter mounting, remote transmitter, IP67, junction box via M20 x 1,5<br />
0: Approvals, without<br />
UMF2<br />
C: <br />
Mounting, remote transmitter IP67 standard, incl. 2,5m cable and wall mounting bracket<br />
Thread - electrical connection, ½" NPT (f)<br />
1: Display and control unit, integrated<br />
1: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
G: Output:<br />
current output 1: 4 - 20mA with HART-protocol<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
0BH: Design, Heinrichs<br />
1: Extended cable length, 5m standard on remote version (breakout cable), IP67

<strong>VARIABLE AREA FLOWMETER<br />
Modelo: V31-320B3F-02-E3W-B-F-S-0-0-2-0-0-0-0-0-H<br />
Marca: Kobold-Heinrichs</strong><br />
Max. 6 bar<br />
Temp. min. -10 °C, max. 80 °C<br />
Accuracy: 1,6% Liquid <br />
320B3S: Flange, DN50 PN10/16 Form B1 EN1092-1, length: 425 mm Material, SS<br />
02: Type of float, Material, Stainless steel 1.4571 - guided<br />
E3W: Measuring range - stainless steel float (guided), H2O: 650 - 6500 l/h (1000kg/m³, 1mPas)<br />
B: Gasket, EPDM<br />
F: Float-stop, PVDF<br />
S: Union nut, Stainless steel

EP-P-309B-1-HH-2-0/UMF2-C-1-1-G-0BH-1<br />
Magnetic inductive flowmeter<br />
Brand: Kobold-Heinrichs<br />
P: PTFE (PFA), standard 3 Hastelloy electrodes -20°C...150°C<br />
309B:<br />
DN25 PN40 Form B1 DIN EN 1092-1<br />
Max. measuring range (Water 20°C, 1 mPas), 17.6 m³/h<br />
1: Material flanges, steel (painted)<br />
HH: Material electrodes, Hastelloy C-4 incl. grounding electrode standard for PTFE<br />
1: Transmitter mounting, remote transmitter, IP67, junction box via M20 x 1,5<br />
0: Approvals, without<br />
UMF2<br />
C:<br />
Mounting, remote transmitter IP67 standard, incl. 2,5m cable and wall mounting bracket<br />
Thread - electrical connection, ½" NPT (f)<br />
1: Display and control unit, integrated<br />
1: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
G: Output:<br />
current output 1: 4 - 20mA with HART-protocol<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
0BH: Design, Heinrichs<br />
1: Extended cable length, 5m standard on remote version (breakout cable), IP67

DMH-1-L40-H-1-1-A-2-5<br />
Electromagnetic Flowmeter DMH<br />
MODEL: DMH-1-L40-H-1-1-A-2-5<br />
MARCA: KOBOLD<br />
DMH-1:<br />
Mounting position, all directions<br />
Display / Protection class, LCD Display / IP 67<br />
Output, Analogue, frequency, connection and status output<br />
max. medium temperature, 80 °C<br />
Connection, St. steel<br />
Coating, hard rubber<br />
L40: Connection flange ASME 16.5/MB, 1 1/2" 150 lbs/max. 0..38 m³/h<br />
H: Lining, hard rubber<br />
1: Electrodes material, st.st.<br />
1: Grounding Electrodes material, st.st.<br />
A: Version/cable length, compact version, 1/2 NPT connection<br />
2: Electronic, UMF2(B)-Electronic with HART®<br />
5: Power supply/Cable entries, 230 VAC/1/2 NPT<br />
Datasheet:<br />
http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/es/s5es_dmh.pdf

<strong>Electromagnetic Flowmeter DMH<br />
MODEL: DMH-1-A25-H-1-1-A-2-5<br />
MARCA: KOBOLD</strong><br />
DMH-1:<br />
Mounting position, all directions<br />
Display / Protection class, LCD Display / IP 67<br />
Output, Analogue, frequency, connection and status output<br />
max. medium temperature, 80 °C<br />
Connection, St. steel<br />
Coating, hard rubber<br />
A25: Connection flange DIN EN 1092-1/MB, DN 25 PN 40/max. 0..17 m³/h<br />
H: Lining, hard rubber<br />
1: Electrodes material, st.st.<br />
1: Grounding Electrodes material, st.st.<br />
A: Version/cable length, compact version, 1/2 NPT connection<br />
2: Electronic, UMF2(B)-Electronic with HART®<br />
5: Power supply/Cable entries, 230 VAC/1/2 NPT

BGN-S-15203RJ-0-F-0-0-S-5-0 (25-250 l/h)<br />
Variable Area Flowmeter-All Metal BGN<br />
MODEL: BGN-S-15203RJ-0-F-0-0-S-5-0 (25-250 l/h)<br />
BRAND: KOBOLD<br />
BGN-S:<br />
 Operating principle, variable área<br />
 Mounting position, vertical<br />
 Flow direction, from bottom to the top<br />
 Material tube, st. st.<br />
 Accuracy, 1, 6% F.S<br />
 Max. Temperature, 350°C0<br />
 Max. Pressure, class 150<br />
10203RD: Measuring range water, 25-250 l/h<br />
0:     Heating/cooling, without<br />
F:     Damping/spring stop, with liquid damping<br />
0:     Draining body, without<br />
0:     Certificates, without<br />
S: Display material, Aluminium<br />
5: Display Media measuring range<br />
0: Electrical output, without (sin salida)<br />
Datasheet:<br />
http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/gb/s2gb_bgn.pdf

BGN-S-10203RD-0-0-0-0-S-5-0 (2.5-25 l/h)<br />
Variable Area Flowmeter-All Metal BGN<br />
MODEL: BGN-S-10203RD-0-0-0-0-S-5-0 (2.5-25 l/h)<br />
BRAND: KOBOLD<br />
BGN-S:<br />
    Operating principle, variable área<br />
    Mounting position, vertical<br />
    Flow direction, from bottom to the top<br />
    Material tube, st. st.<br />
    Accuracy, 1, 6% F.S<br />
    Max. Temperature, 350°C0<br />
    Max. Pressure, class 150<br />
10203RD: Measuring range water, 2.5-25 l/h<br />
0:     Heating/cooling, without<br />
0:     Damping/spring stop, without<br />
0:     Draining body, without<br />
0:     Certificates, without<br />
S:    Display material, Aluminium<br />
5:    Display Media measuring range<br />
0:    Electrical output, without (sin salida)<br />
Datasheet:<br />
http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/gb/s2gb_bgn.pdf

All-Metal Variable Area Flowmeter <br />
BGN-S-50206RQ-0-0-0-0-S-5-0 (400-4000 l/h)<br />
Variable Area Flowmeter-All Metal BGN<br />
MODEL: BGN-S-50206RQ-0-0-0-0-S-5-0 (400-4000 l/h)<br />
BRAND: KOBOLD<br />
BGN-S:<br />
    Operating principle, variable área<br />
    Mounting position, vertical<br />
    Flow direction, from bottom to the top<br />
    Material tube, st. st.<br />
    Accuracy, 1, 6% F.S<br />
    Max. Temperature, 350°C0<br />
    Max. Pressure, class 150<br />
50206RQ: Measuring range water, 400-4000 l/h<br />
0:     Heating/cooling, without<br />
0:     Damping/spring stop, without<br />
0:     Draining body, without<br />
0:     Certificates, without<br />
S:    Display material, Aluminium<br />
5:    Display Media measuring range<br />
0:    Electrical output, without (sin salida)<br />
Datasheet:<br />
http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/gb/s2gb_bgn.pdf

<div>BGN-S-10202RA-0-0-0-0-S-5-0 (0.7-7 l/h)</div>

<div>Variable Area Flowmeter-All Metal BGN</div>

<div>MODEL: BGN-S-10202RA-0-0-0-0-S-5-0 (0.7-7 l/h)</div>

<div>BRAND: KOBOLD</div>

<div>BGN-S:</div>

<div>Operating principle, variable área</div>

<div>Mounting position, vertical</div>

<div>Flow direction, from bottom to the top</div>

<div>Material tube, st. st.</div>

<div>Accuracy, 1, 6% F.S</div>

<div>Max. Temperature, 350°C0</div>

<div>Max. Pressure, class 150</div>

<div>10202RA: Measuring range water, 0,5-5 (0,7-7) L/h </div>

<div>0:     Heating/cooling, without</div>

<div>0:     Damping/spring stop, without</div>

<div>0:     Draining body, without</div>

<div>0:     Certificates, without</div>

<div>S:<span> </span>Display material, Aluminium</div>

<div>5:<span> </span>Display Media measuring range</div>

<div>0:<span> </span>Electrical output, without (sin salida)</div>

<div>Datasheet:</div>

<div>http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/gb/s2gb_bgn.pdf</div>

EP-H-214R-1-SS-2-0/UMF2-C-1-2-G-0BH-3 (1896m3/h)<br />
Magnetic inductive flowmeter<br />
Brand: Kobold-Heinrichs<br />
H: hard-rubber, standard 3 stainless steel electrodes 0°C...80°C<br />
214R:<br />
Process Connection, 10" Class 150 RF ASME B16.5-2003<br />
Max. measuring range (Water 20°C, 1 mPas), 1896 m³/h<br />
1: Material flanges, steel (painted)<br />
SS: Material electrodes, Stainless steel incl. grounding electrode<br />
2: Transmitter mounting, remote transmitter (IP67, junction box via M20 x 1,5)<br />
0: Approvals, without<br />
UMF2<br />
C:<br />
Mounting, remote transmitter<br />
Connection to sensor, incl. 2,5m cable and wall mounting bracket<br />
Thread - Electrical connection, cable >10m c/w term.conn box on transmitter - ½" NPT (f)<br />
1: Display and control unit, integrated<br />
2: Power supply, 115V AC (+10%, -15%), 50/60Hz<br />
G: Output:<br />
current output 1: 4 - 20mA with HART-protocol<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
0BH: Design, Heinrichs<br />
3: Extended cable length, 15m (add. Junction box on transmitter)<br />
Datasheet:<br />
http://www.heinrichs.eu/uploads/tx_rsbproductdownload/ep_umf2b_db_en.pdf

Magnetic inductive flowmeter<br />
EP-H-217R-1-SS-2-0/UMF2-C-1-2-G-0BH-3 (4300m3/h)<br />
Brand: Kobold-Heinrichs<br />
H: hard-rubber, standard 3 stainless steel electrodes 0°C...80°C<br />
217R:<br />
Process Connection, 16" Class 150 RF ASME B16.5-2003<br />
Max. measuring range (Water 20°C, 1 mPas), 4300 m³/h<br />
1: Material flanges, steel (painted)<br />
SS: Material electrodes, Stainless steel incl. grounding electrode<br />
2: Transmitter mounting, remote transmitter (IP67, junction box via M20 x 1,5)<br />
0: Approvals, without<br />
UMF2<br />
C:<br />
Mounting, remote transmitter<br />
Connection to sensor, incl. 2,5m cable and wall mounting bracket<br />
Thread - Electrical connection, cable >10m c/w term.conn box on transmitter - ½" NPT (f)<br />
1: Display and control unit, integrated<br />
2: Power supply, 115V AC (+10%, -15%), 50/60Hz<br />
G: Output:<br />
current output 1: 4 - 20mA with HART-protocol<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
0BH: Design, Heinrichs<br />
3: Extended cable length, 15m (add. Junction box on transmitter)<br />
Datasheet:<br />
http://www.heinrichs.eu/uploads/tx_rsbproductdownload/ep_umf2b_db_en.pdf<br />


EP-P-201R-1-HH-1-0/UMF2-A-1-2-G-0BH-0<br />
Magnetic inductive flowmeter<br />
Brand: Kobold-Heinrichs<br />
P: PTFE (PFA), standard 3 Hastelloy electrodes -20°C...150°C<br />
201R: <br />
Process Connection, ½ "Class 150 RF ASME B16.5-2003<br />
Max. measuring range (Water 20°C, 1 mPas), 6 m³/h<br />
1: Material flanges, steel (painted)<br />
HH: Material electrodes, Hastelloy C-4 incl. grounding electrode standard for PTFE<br />
1: Transmitter mounting, integrated transmitter (IP67)<br />
0: Approvals, without<br />
UMF2<br />
A: <br />
Mounting, integrated transmitter IP67 standard<br />
Thread - electrical connection, ½" NPT (f)<br />
1: Display and control unit, integrated<br />
2: Power supply, 115V AC (+10%, -15%), 50/60Hz<br />
G: Output:<br />
current output 1: 4 - 20mA with HART-protocol<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
0BH: Design, Heinrichs<br />
0: Extended cable length, 2,5m standard on remote version (breakout cable)<br />
Datasheet:<br />
http://www.heinrichs.eu/uploads/tx_rsbproductdownload/ep_umf2b_db_en.pdf

DAK-2-3-05H-F-40<br />
Flow Indicator with Flap DAK-2<br />
DAK-2:<br />
Operating principle, Flap<br />
Mounting position, Horizontal<br />
Flow direction, in direction of the arrow<br />
max. temperature, 150 °C (Option B: 280 °C)<br />
max. pressure, 16 bar (Option 25 or 40 bar)<br />
3: Housing, cast steel<br />
05H: Nom. diameter, 40<br />
F: Flanges, flange acc. EN 1092-1<br />
40: DN 40 / 1 1/2"

Electronic, UMF2(B)-Electronic with HART®

DMH-1-C1H-H-1-1-A-1-5<br />
Electromagnetic Flowmeter DMH<br />
MODEL: DMH-1-C1H-H-1-1-A-1-5<br />
MARCA: KOBOLD<br />
DMH-1:<br />
Mounting position, all directions<br />
Display / Protection class, LCD Display / IP 67<br />
Output, Analogue, frequency, connection and status output<br />
max. medium temperature, 80 °C<br />
Connection, St. steel<br />
Coating, hard rubber<br />
C1H: Connection flange DIN EN 1092-1/MB, DN 100 PN 16/max. 0..288 m³/h<br />
H: Lining, hard rubber<br />
1: Electrodes material, st.st.<br />
1: Grounding Electrodes material, st.st.<br />
A: Version/cable length, compact version, 1/2 NPT connection<br />
1: Electronic, UMF2 (B)-Electronic<br />
5: Power supply/Cable entries, 230 VAC/1/2 NPT<br />
Datasheet:<br />
http://www.koboldmessring.com/fileadmin/koboldfiles/pdf/es/s5es_dmh.pdf

<strong>Electromagnetic Flowmeter DMH<br />
MODEL: DMH-2-A50-H-1-1-A-1-3<br />
MARCA: KOBOLD</strong><br />
DMH-1:<br />
Mounting position, all directions<br />
Display / Protection class, LCD Display / IP 67<br />
Output, Analogue, frequency, connection and status output<br />
max. medium temperature, 80 °C<br />
Connection, St. steel<br />
Coating, hard rubber<br />
A50: Connection flange DIN EN 1092-1/MB, DN 50 PN 40/max. 0..62 m³/h<br />
H: Lining, hard rubber<br />
1: Electrodes material, st.st.<br />
1: Grounding Electrodes material, st.st.<br />
A: Version/cable length, compact version, 1/2 NPT connection<br />
1: Electronic, UMF2 (B)-Electronic<br />
5: Power supply/Cable entries, 230 VAC/1/2 NPT

<strong>Paddle Flow Switch<br />
Model: FPS-5-1-00P<br />
Brand: Kobold (Alemania)</strong><br />
[FPS]<br />
Operating principle, paddle bellow<br />
Mounting position, paddle all directions<br />
Bellow, bronze <br />
Output/SPDT microswitch<br />
Connection, screw-in<br />
material, brass <br />
Max. temperature 120 °C<br />
Max. pressure, 11 bar <br />
[5] Connection c/w 1 NPT, standard <br />
[1] Material: Brass <br />
[00P] Design Standard switching range

<strong>Paddle Bellows Flow Switch<br />
Brand: Alemania (Kobold)<br />
Modelo: FPS-5-2-00P</strong><br />
[FPS]:<br />
Stainless Steel Design: Paddle: stainless steel 316L<br />
Max. Media Temperature: -40 ... 250°F<br />
Max. Ambient Temp: -30 ... 150°F<br />
Max. Allowed Pressure: Stainless Steel 435 PSIG<br />
Max. Pressure Loss: Approx. 0.15 ... 0.44 PSIG<br />
Max. Pressure: 30 bar<br />
[5]: Process Connection: 1" NPT male<br />
[2]: Material: Stainless Steel<br />
[00P]: Design: Standard switching range<br /><br />
Standard switching range<br />
Nominal pipe size: DN150<br />
Water falling: 25.9-81.70 m3/h<br />
Water rising: 43.1-85.10 m3/h
