Variable Area Flowmeter/Monitor<br />
Brand: Kobold<br />
Model: URM-9935H0Y<br />
Mount. Position: Vertical<br />
Protection: IP 67<br />
Range: 63-630 L/h<br />
Instrument Length: 360 mm<br />
Without contact<br />
Special option:<br />
Y: Special option:<br />
Special measuring range 17-170 GPH Water<br />
Distance of connection 375 (1-2) mm<br />
Special connection ½” NPT<br />
Include:<br />
DOK-FR-05<br />
Calibration report with 5 measuring points for model code URM-99

Variable Area Flowmeter<br />
Brand: Kobold – Heinrichs (Alemania)<br />
Model: V3160801S02E5WFFA0020200000H<br />
[V31]: Model <br />
[60801S]: Thread, NPT 2” (F) Screw<br />
Length, 375 mm, connection - wetted parts Stainless Steel <br />
[02]: Type of float, Material, Stainless steel 1.4571-guided, with guide rod 1.4571<br />
[E5W]: Measuring range - stainless steel float (guided)<br />
H2O: (1070-10700 LPH; 282.6-2826.6 GPH), 1000kg/m³, 1mPas <br />
[F]: Gasket, Viton® <br />
[F]: Float Stop, PVDF <br />
[A]: Union nut, Aluminium lacquered <br />
[0]: Shatter protection max. 80°C, without <br />
[0]: Electrical output, without <br />
[2]: Scale, Measuring range-scale (H2O) <br />
[0]: Approvals, without <br />
[2]: Calibration certificate, 5-Points<br />
[0]: Cleaning according works standard (free of oil and grease), without <br />
[0]: Pressure / leakage test, without <br />
[0]: Approvals, without <br />
[0]: Marking, without <br />
[0]: Accessories, without <br />
[H]: Make, Heinrich

<strong>Variable Area Flowmeter<br />
Model: V3160501S01D6WFFA0020200000H<br />
Brand: Kobold – Heinrichs</strong><br />
[V31]: Model <br />
[60501S]: Thread, NPT 1"(F) Screw<br />
Length, 375 mm, connection - wetted parts Stainless Steel <br />
[01]: Type of float, Material, Stainless steel 1.4571, guide rod 1.4571, without <br />
[D6W]: Measuring range - stainless steel float with guide and not guided, <br />
H2O: (170-1700 LPH; 44.90-449.09 GPH), 1000kg/m³, 1mPas <br />
[F]: Gasket, Viton® <br />
[F]: Float Stop, PVDF <br />
[A]: Union nut, Aluminium lacquered <br />
[0]: Shatter protection max. 80°C, without <br />
[0]: Electrical output, without <br />
[2]: Scale, Measuring range-scale (H2O) <br />
[0]: Approvals, without <br />
[2]: Calibration certificate, 5-Points<br />
[0]: Cleaning according works standard (free of oil and grease), without <br />
[0]: Pressure / leakage test, without <br />
[0]: Approvals, without <br />
[0]: Marking, without <br />
[0]: Accessories, without <br />
[H]: Make, Heinrich

Variable Area Flowmeter<br />
Brand: Kobold – Heinrichs (Alemania)<br />
Model: V3160401S01D2WFFA0020200000H<br />
[V31]: Model<br />
[60401S]: Thread, NPT 3/4"(F) Screw<br />
Length, 375 mm, connection - wetted parts Stainless Steel<br />
[01]: Type of float, Material, Stainless steel 1.4571, guide rod 1.4571, without<br />
[D2W]: Measuring range - stainless steel float with guide and not guided,<br />
H2O: (65-650 LPH; 17.17-171.7 GPH), 1000kg/m³, 1mPas<br />
[F]: Gasket, Viton®<br />
[F]: Float Stop, PVDF<br />
[A]: Union nut, Aluminium lacquered<br />
[0]: Shatter protection max. 80°C, without<br />
[0]: Electrical output, without<br />
[2]: Scale, Measuring range-scale (H2O)<br />
[0]: Approvals, without<br />
[2]: Calibration certificate, 5-Points<br />
[0]: Cleaning according works standard (free of oil and grease), without<br />
[0]: Pressure / leakage test, without<br />
[0]: Approvals, without<br />
[0]: Marking, without<br />
[0]: Accessories, without<br />
[H]: Make, Heinrich

Compact Magneto-Inductive Flowmeter -Model MIK<br />
Model: MIK-6FC-U2-A-L443<br />
Brand: Kobold USA<br />
[MIK-6FC]<br />
Measurement Process: Electromagnetic<br />
Mounting Position: Universal, Flow in Direction of the Arrow<br />
Ambient Temperature: 14 ... 140 °F<br />
Max. Pressure: 145 psi<br />
Protection, IP 65<br />
PVDF-housing, FFKM-seal,<br />
Hastelloy- electrode<br />
[U2]: Measuring Range, Native, Process Connection, 2.4...48.0 GPH, G ½<br />
[A]:  Optional Fitting Set, without<br />
[L443]: Output/Electronics, DIN-plug, 4 - 20 mA

Pelton Wheel Flow Meter<br />
Brand: Kobold (Alemania)<br />
Model: DPE-11-25-N9-E34R<br />
Operating principle: Pelton Wheel (6-vane)<br />
Mounting position / flow direction: in all directions/ in direction of the arrow<br />
Protection: IP 65<br />
Max. temperature: 80 °C<br />
Max. pressure: PN 40<br />
Accuracy of final value: +/-2,5%<br />
Material Housing: Brass casting<br />
Material Axis. Hard metal<br />
[25]: Measuring range, 30-350 L/min<br />
[N9]: Mech. connection, 2 NPT female<br />
[E34R]: ZED-evaluating electronics,<br />
Counter electronic, supply 24 VDC, 0(4)-20 mA, 2 SPDT

<strong>Paddle Wheel Flowmeter<br />
Brand: Kobold USA<br />
Model: DRB-1155N5-C34P</strong><br />
[DRB-1155]:<br />
Range flow (GPM): 3-13<br />
Material: Brass<br />
[N5]: Process Connection; 3/4" NPT<br />
[C34P]: Evaluating Electronics; LED-Display,<br />
4-20 mA, 1 x Open Collector PNP,<br />
Plug Connector M12 x 1<br />

Compact Vortex Flowmeter<br />
Brand: Kobold USA<br />
Model: DVZ-1-1-04-N2-L443<br />
Accuracy: ± 2.5% of Full Scal<br />
Media Temp. Range: 32...176°F<br />
Electrical Protection: IP 65<br />
[DVZ-1]: Housing/Bluff Body, PPS/PPS<br />
[1]: Fitting/Seals, Brass/NBR<br />
[04]: 0.5...4.5 LPM<br />
[N2]: Connections Fixed, 1/4" NPT<br />
[L443]: Analog Output, DIN-plug, 4-20 mA

<strong>Plastic Flowmeter/-switch<br />
Brand: Kobold (Alemania)<br />
Model: KSM-1-601-Q-T65-R0</strong><br />
[KSK-1]<br />
Operating principle, variable area<br />
Mounting position, vertical<br />
Flow direction, from bottom<br />
Armature material, Trogamide<br />
Accuracy, ±4 % FS<br />
Max. temperature, 60 °C<br />
Max. pressure, 16 bar<br />
[601]: Measuring range, 8 - 60  water m³/h<br />
[Q]: either scales for liquid, media m³/h water<br />
[T65]: Option connection, Cast iron G 2 1/2 female<br />
[R0]: Option contact, w/o contact

EP-H-204R-1-S-S-1-0/UMF2-A-1-1-F-0BH<br />
Magnetic inductive flowmeter<br />
Brand: Kobold-Heinrichs<br />
[EP-H]: hard-rubber, standard 3 stainless steel electrodes 0°C...80°C<br />
[204R]: Process Connection, 1¼" Class 150 RF ASME B16.5-2003<br />
Max. measuring range (Water 20°C, 1 mPas), 28 m³/h<br />
[1]: Material flanges, steel (painted)<br />
[S]:Material electrodes, Stainless steel, standard for hard rubber, soft rubber<br />
[S]: Earthing electrode (from DN20...), Stainless steel, standard for hard rubber, soft rubber<br />
[1]: Transmitter mounting, integrated transmitter. Protection class sensor, IP67<br />
[0]: Approvals, without<br />
[UMF2]<br />
[A]: Mounting, integrated transmitter IP67 standard<br />
Electrical connection, ½" NPT (f)<br />
[1]: Display and control unit, integrated<br />
[1]: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
[F]: Output:<br />
current output 1: 0(4) - 20mA<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
[0BH]: Design, Heinrichs

Variable Area Flowmeter<br />
Brand: Kobold – Heinrichs<br />
Model: V31-203R3F-03-C5W-F-F-A-0-3-2-0-0-0-0-0-0-0-H<br />
[V31]: Model,<br />
[203R3F]: Flange, 1" 150lbs RF ASME B16.5-2003,<br />
Length 425 mm, Connection – Wetted parts, Stainless steel<br />
[03]: Type of float, Material, Stainless steel 1.4571 - with magnet, without guide rod 1.4571<br />
[C5W]: Measuring range - stainless steel float with magnet H2O: 0.54 – 5.4 L/min<br />
[F]: Gasket, Viton<br />
[F]: Float – stop, PVDF<br />
[A]: Union nut, Aluminium lacquered<br />
[0]: Shatter protection max. 80°C, without<br />
[3]: Electrical output, 1 x K 33 two way contact (SPDT)<br />
[2]: Scale, Measuring range-scale (H2O)<br />
[0]: Approvals, without<br />
[0]: Calibration certificate, without<br />
[0]: Cleaning according works standard (free of oil and grease), without<br />
[0]: Pressure / leakage test, without<br />
[0]: Approvals, without<br />
[0]: Marking, without<br />
[0]: Accessories, without<br />
[H]: Make, Heinrichs

Differential Pressure Flow Meter / Monitor<br />
Model: RCD-11-14H-N6-ZLT<br />
Brand: Kobold (Alemania)<br />
[RCD-11]:<br />
Operating principle Venturi-nozzle<br />
Mounting position all directions<br />
Flow direction in direction of the arrow<br />
Protection class IP 65<br />
max. temperature 80 °C (100 °C)<br />
max.pressure 40 bar<br />
Material Brass casting<br />
[14H]: Measuring range, 10-58 L/min water<br />
[N6]: Process Connection,  1 NPT female  <br />
[ZLT]: Evaluating electronics, mech. pointer indication<br />
Flow from left/indication on top p

Electro Magnetic Flowmeter Sensor/Transmitter UMF2<br />
Model Sensor: PIT-S-206R-263-H-0-1-0-0-L-H<br />
[PIT]: Model Sensor (PIT-520)<br />
[S]: Model, Stainless steel (1.4571/1.4404)/PTFE for diameters DN125 - DN2000 (PN16);Tmax. = 100°C<br />
[206R]: Process connection, 2" Class 150 RF ASME B16.5-2003<br />
[263]: Special length, 236 mm<br />
[H]: Electrode Material, Hastelloy C-4<br />
[0]: Earthing Electrode, without<br />
[1]: Sensor configuration, Integral mount transmitter<br />
[0]: Approvals, without approval<br />
[0]: Certificate, without<br />
[L]: Supplementary equipment, Special design for flow-velocity 0,5 m/s - 5 m/s<br />
[H]: Design, Heinrichs<br />
 <br />
[UMF2]: Model Transmitter<br />
[A]: Mounting, integrated transmitter IP67 standard  <br />
Conduit port opening, ½" NPT (f)<br />
[1]: Display / Interface board, Integral within transmitter housing<br />
[1]: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
[G]: Outputs,<br />
Analog output 1: 4 - 20mA with HART®<br />
Pulse output: passive 24V DC<br />
Status output: passive Um=24V DC<br />
[0BH]: Design, Heinrichs

Mass Flowmeter-Thermal KES<br />
Brand: Kobold (Alemania)<br />
Model: KES-1-015-K-D-3-4<br />
[KES-1]<br />
Function principle, Direct thermal flow<br />
Mounting position, all directions<br />
Version, inserting version<br />
Output, Analogue/contact<br />
Max. temperature, 80°C<br />
Max. pressure, 8 bar<br />
Sensor material, St.st. <br />
[015]: mounting length/connection, 15 cm<br />
[K]: electronic version, Compact version<br />
[D]: Display, LCD-display, backlight, 2x12 digit<br />
[3]: Power supply, 18-30 VDC<br />
[4]: Analogue output, 4-20 mA<br /><br />
Include:<br />
Accessories for KES<br />
Model: KES-Z E10 N15<br />
Connection,  3/8"-pipe x 1/2 NPT male

Calorimetric Flow Monitor-for air<br />
Brand: Kobold(Alemania)<br />
Model: KAL-L-81N1WK-N4<br />
[KAL-L]:<br />
Operating principle, calorimetric<br />
Mounting position, all directions<br />
Indication, DUO-LED and LED-chain<br />
Relais output, SPDT<br />
max. temperature, 120 °C<br />
max. pressure, 8 bar<br />
Protection class, IP 65<br />
[81N1WK]: Connection, Compression fitting 1/2" NPT<br />
[N4]: Electron. connection/power supply, 1/2 NPT for screwed cable gland - 24 VDC/AC

<div>Model Sensor: EP-H-213R-0-S-S-1-0/UMF2-A-1-1-F-0BK<br />
Brand: Kobold – Heinrichs<br />
[EP-H]:<br />
Material - lining, hard-rubber<br />
standard 3 stainless steel electrodes, Temperature, 0°C...80°C<br />
[213R]: Process Connection, 8" Class 150 RF ASME B16.5-2003<br />
Max. measuring range (Water 20°C, 1 mPas), 1118 m³/h<br />
Installation length, 350 mm<br />
[0]: Material flanges, without<br />
[S]: Material electrodes, Stainless steel,<br />
[S]: Earthing electrode, Stainless steel,<br />
[1]: Transmitter mounting, integrated transmitter<br />
Protection class sensor, IP67 <br />
[0]: Approvals, without</div>

<div>[UMF2-A]:<br />
Mounting, integrated transmitter IP67 standard<br />
Thread - electrical connection, ½" NPT (f)<br />
[1]: Display and control unit, integrated<br />
[1]: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
[F]: Output:<br />
current output 1: 0(4) - 20mA<br />
pulse output: passive Um=24VDC<br />
status output: passive Um=24VDC<br />
[0BK]: Design, Kobold<br />
Include:<br />
2 Ground Disc / Sensor DN200 8 inch stainless steel</div>

Oval Gear Flow Meter/Counter.<br />
Model: DON-1-20H-N4-1-Z3-M-0<br />
Brand: Kobold<br />
[DON-1]:<br />
Operating principle Gear Wheel<br />
Mounting position horizontal / vertical<br />
Flow direction in direction of the arrow<br />
max. temperature 80 °C<br />
max. pressure, 16...64 bar<br />
Accuracy ±0,2 % …1 % of reading<br />
Housing material Aluminium<br />
Rotor material PPS<br />
[20H]: Measuring range,1-40 L/min<br />
[N4]: Mech. connection, for meas. range 20H, 1/2 NPT  <br />
[1]: Seal, FKM  <br />
[Z3]: Electronic, dual LCD totaliser/rate, outputs: pulse, analogue<br />
[M]: Cable entry, M20<br />
[0]: Options, without<br />
* Not include Battery

<strong>Pelton Wheel Flow Meter<br />
Model: DRB-11-20-N8-L442<br />
Brand: Kobold</strong><br />
[DRB-11]: <br />
Operating principle, Pelton Wheel (4-vane)<br />
Mounting position / flow direction, in all directions/ in direction of the arrow<br />
Protection IP 65<br />
Max. temperature 80 °C<br />
Max. pressure, 16bar<br />
Accuracy of final value, +/-3%<br />
Material Housing Brass casting <br />
Material Axis Hard metal <br />
[20]: Measuring range 25-250 L/min <br />
[N8]: Mech. connection, for MR-Code: 20, 1 1/2 NPT female<br />
[L442]: Electronic, Analogue output 4-20 mA, DIN-plug, 2-wire

All-Metal-Flowmeter / Switch<br />
Brand: Kobold (Alemania)<br />
Model: SMV-32-09H-U0-R15<br />
[SMV-32]:<br />
Operating principle, variable area<br />
Mounting position, vertical<br />
Flow direction, from bottom<br />
Body material, St.St.<br />
Seal, FPM<br />
Side mounted indication, yes<br />
Switch point, adjustable<br />
Accuracy ±5 % FS<br />
Max. temperature 100 °C<br />
Max. pressure 350 bar<br />
[09H]: Adjustment range, 1...9 L/min water<br />
[U0]: Contact, 1 SPDT<br />
[R15]: Connection, G 1/2 female

<strong>Flowindicator for Horizontal Mounting<br />
Model: DKB-11-06H-R-25<br />
Brand: Kobold (Alemania)</strong><br />
[DKB]:<br />
Operating principle, Ball<br />
Mounting position, horizontal<br />
Flow direction in direction of the arrow<br />
Housing material, brass <br />
max. temperature, 120 °C <br />
max. pressure, 6 bar<br />
[11]: Material (rotating vane or ball); POM<br />
[06H]: Nom. diameter/ind. 1"; 0,14...105 L/min water<br />
[R]: Thread, G-thread female<br />
[25]: Connection, 1"
