Manometro contactos, 0 a 10 bar, G1/2, 160 mm
BOURDON TUBE PRESSURE GAUGE WITH ELECTRICAL CONTACT <br />
FOR CHEMICAL APPLICATIONS WITH BACKFLANGE<br />
Brand: AFRISO (Germany) <br />
Nominal size: 160 mm<br />
Connection: G ½ B bottom<br />
Range: 0 / 10 bar<br />
Housing: Stainless steel 304 with Bayonet bezel 304 and backflange 304 (vibratory finished)<br />
Filling fluid: Housing suitable for filling with silicon oil (but not filled)<br />
Wetted parts: Edelstahl 316 Ti / 316 L<br />
Window: Plastic (Makrolon) with adjustment device<br />
Accuracy class: 1.0<br />
Electrical contact: Double Snap action contact (magnet) <br />
MK2.12 Switching function clockwise: <br />
1st contact normally open (NO): closes with rising pressure <br />
2nd contact normally closed (NC): opens with rising pressure<br />
Electrical connection: Junction box
| Brand: AFRISO |
| Línea: AFRISO-ESPECIALES (CM) |
