<strong>Paddle Type Flow Switch<br />
Brand: Kobold (Alemania)<br />
Model: PSR-12-201-R-20-R-1</strong><br />
[PSR-12]<br />
Operating principle, paddle<br />
Mounting position, all directions<br />
incl. fitting, st. st<br />
Body material, st. st<br />
max. pressure* 250 bar<br />
* only 25 bar at PSR-..32 and PSR-..40<br />
[201] Measuring range/paddle, 34.6-48.3 L/min paddle: 1 <br />
[R] Connection, G-thread<br />
[20] Connection, 3/4" (for PSR-xx20...)<br />
[R] Contact version, N/O<br />
[1] Connecting cable, PVC-cable 1.5 m (standard)

<strong>Baffle Plate System Flow Transmitter for Liquids<br />
Brand: Kobold (Alemania)<br />
Model: DWD-17-N15-3-T-R-0</strong><br />
[DWD-17]<br />
Operating principle: Baffle plate system<br />
Indication: LCD-display<br />
Flow direction: in directon of the arrow<br />
Output: 2 switching contacts + 4-20 mA<br />
Max. temperature: 60 °C<br />
Connection: thread<br />
Material (T-piece): PVC<br />
[N15] Connection size, 1/2 NPT female<br />
[3] Power supply, 24 VDC<br />
[T] Flow direction, from top to bottom <br />
[R] Mounting position, right of the lead <br />
[0] Option, w/o further options

<strong>Baffle Plate System Flow Transmitter for Liquids<br />
Brand: Kobold (Alemania)<br />
Model: DWD-17-N10-3-T-R-0</strong><br />
[DWD-17]<br />
Operating principle: Baffle plate system<br />
Indication: LCD-display<br />
Flow direction: in directon of the arrow<br />
Output: 2 switching contacts + 4-20 mA<br />
Max. temperature: 60 °C<br />
Connection: thread<br />
Material (T-piece): PVC<br />
[N10] Connection size, 3/8 NPT female <br />
[3] Power supply, 24 VDC<br />
[T] Flow direction, from top to bottom <br />
[R] Mounting position, right of the lead <br />
[0] Option, w/o further options

<strong>Paddle Flow Switch<br />
Brand: Kobold (Alemania)<br />
Model: PPS-1-2-02</strong><br />
[PPS]: Operating principle, paddle<br />
Mounting position paddle, vertical<br />
Mounting position piping, horizontal<br />
Bellow, w/o<br />
Output/SPDT, reed contact<br />
Connection, screw-in<br />
material, polysulfone<br />
Max. temperature, 105  °C<br />
Max. pressure, 10 bar<br />
[1] Connection,  G 1 male <br />
[2]: Material, Polysulfone<br />
[02]: Design, Contact N/O

<div><strong>Rotating Vane Flow Meter <br />
Brand: Kobold(Alemania)<br />
Model: DPM-1-5-07-N2-C34P</strong><br />
[DPM-1]:<br />
Operating principle: Rotating vane <br />
Mounting position: all directions<br />
Flow direction: in direction of the arrow<br />
max. temperature: 80°C<br />
max. pressure: 16bar<br />
Accuracy: +/-1,0 (2,5)%<br />
Protection: IP65<br />
[5]: Material, st. st.<br />
[07]: Measuring range, 50-700 mL/min<br />
[N2]: Mech. connection, 1/4 NPT female<br />
[C34P]: Evaluating Electronic, Compact electronics, 4-20mA, 1x PNP</div>

<strong>Paddle Type Flow Switch<br />
Brand: Kobold(Alemania)<br />
Model: PSE-21-498-N-15-R-1</strong><br />
[PSE-21]:<br />
Operating principle: paddle<br />
Mounting position: horizontal<br />
Approvals: ATEX/IECEx<br />
Body material: brass <br />
max. pressure*: 100 bar <br />
[498]: Measuring range/paddle, Paddle length: 49mm(60mm for NPT)<br />
[N]: Connection, NPT-thread<br />
[15]: Connection, 1/2" <br />
[R]: Contact version, N/O (ATEX IECEx) <br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)

Baffle Plate System Flow Transmitter for Liquids<br />
Brand: Kobold(Alemania)<br />
Model: DWD-36-W3H-3-L-T-0<br />
[DWD-36]:<br />
Operating principle: Baffle plate system<br />
Indication: LCD-display<br />
Flow direction: in directon of the arrow<br />
Output: 2 switching contacts + 4-20 mA<br />
Max. temperature: 120 °C<br />
Connection: weld on <br />
Material (T-piece): st. st.<br />
[W3H]: Connection size, for pipe size DN 300<br />
[3]: Power supply, 24 VDC<br />
[L]: Flow direction, from left to right<br />
[0]: Option, w/o further options

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD (Alemania)<br />
Model: PSE-22-520-N-15-R-1-H<br />
[PSE-22]:<br />
Operating principle, paddle<br />
Mounting position, horizontal<br />
Approvals, ATEX / IECEx<br />
Body material, st. st.<br />
max. pressure, 250 bar<br />
[520]: Measuring range/paddle, Paddle length: 52 mm(58 mm for NPT)<br />
[N]: Connection, NPT-thread<br />
[15]: Connection, 1/2"<br />
[R]: Contact version, N/O<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)<br />
[H]: Special version, Medium temperature +110°C, marking according to approval

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD (Alemania)<br />
Model: PSE-22-520-N-15-R-1<br />
[PSE-22]:<br />
Operating principle, paddle<br />
Mounting position, horizontal<br />
Approvals, ATEX / IECEx<br />
Body material, st. st.<br />
max. pressure, 250 bar<br />
[520]: Measuring range/paddle, Paddle length: 52 mm(58 mm for NPT)<br />
[N]: Connection, NPT-thread<br />
[15]: Connection, 1/2"<br />
[R]: Contact version, N/O<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-11-32B-R-32-U-1<br />
[PSR-11]:<br />
Operating principle, paddle<br />
Mounting position, all directions<br />
Incl. fitting, brass<br />
Body material, brass<br />
max. pressure, 100 bar<br />
[32B]: Measuring range/paddle, 22-38.6 L/min paddle: 12<br />
[R]: Connection, G-thread<br />
[32]: Connection, 32<br />
[U]: Contact version, SPDT (ATEX IECEx)<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD (USA)<br />
Model: PSR-5225-EC15<br />
[PSR]:<br />
Maximum Temperature: 230°F<br />
Maximum Pressure: 1450 PSIG<br />
Materials:<br />
Paddle: SS 304<br />
Leaf Spring: SS 301<br />
Beam: SS 301<br />
Locking Plate: brass or SS 304<br />
Contact Housing: Polyamid, glass reinforced, NEMA 4<br />
Cable: PVC<br />
O-Ring: NBR for brass units; FKM for SS units<br />
Contact: Reed-switch SPST, N/O or N/C (SPDT Optional)<br />
Maximum Contact Ratings: 50 VA, (50 Watt, 250 VAC, 1.5A)<br />
Standard Cable Length: 5ft<br />
Orientation: Horizontal Pipes<br />
Max Flow: 5x switching range increasing<br />
Switching ranges:<br />
Increasing GPM water: 2.0...4.8<br />
Decreasing GPM water: 1.9...4.5<br />
Connection: 1" NPT<br />
[EC15] Option; SPST w/15 Ft. Cable<br /><br />


PADDLE FLOW MONITOR FOR LIQUIDS PSR<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-12-258-N-25-U-1<br />
Operating principle: Paddle<br />
Mounting position: All directions<br />
Incl. fitting: st.st.<br />
Max. pressure: 250 bar<br />
[258]: Measuring range/paddle, 7.4-18.2 L/min paddle: 8<br />
[N]: Connection, NPT-thread 1"<br />
[25]: Connection, 1"<br />
[U]: Contact version, SPDT<br />
[1]: Connecting cabe, PVC-cable 1.5 m (standard)

Paddle Type Flow Switch<br />
Brand: Kobold(Alemania)<br />
Model: PSR-11-204-N-20-R-1<br />
[PSR-11]:<br />
Operating principle, paddle<br />
Mounting position, all directions<br />
Incl. fitting, brass<br />
Body material, brass<br />
Max. pressure*, 100 bar<br />
[204]: Measuring range/paddle, 20.4-30 L/min paddle: 4<br />
[N]: Connection, NPT-thread<br />
[20]: Connection, 3/4"<br />
[R]: Contact version, N/O<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-11-083-R-08-R-8<br />
[PSR-11]:<br />
Operating principle, paddle<br />
Mounting position, all directions<br />
incl. fitting, brass<br />
Body material, brass<br />
max. pressure, 100 bar<br />
[083]: Measuring range/paddle, 2.3-4.7 L/min paddle: 3<br />
[R]: Connection, G-thread<br />
[08]: Connection, 1/4" (for PSR-xx08...)<br />
[R]: Contact version, N/O<br />
[8]: Connecting cable, PVC-cable 5.0 m<br />
<br />


Paddle Type Flow Switch<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-11-151-N-15-R-1<br />
[PSR-11]:<br />
Operating principle paddle<br />
Mounting position all directions<br />
incl. fitting, brass<br />
Body material, brass<br />
max. pressure, 100 bar<br />
[151]: Measuring range/paddle, 9.2-12.4 L/min paddle: 1<br />
[N]: Connection, NPT-thread<br />
[15]: Connection, 1/2"<br />
[R]: Contact version, N/O<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)

PADDLE TYPE FLOW SWITCH<br />
Brand: KOBOLD<br />
Model: PSR-5125-U<br />
[PSR-5125]:<br />
Switching Tolerance: ± 15%<br />
Media Temperature  Brass/NBR Seal: -4...158 °F<br />
Max. Pressure  Brass: 1/4"...1" = 1450 PSIG,<br />
Ingress Protection: IP 65<br />
Connection, 1" NPT<br />
Approximate switching range<br />
 Increasing GPM (Water), 2.0...4.8 GPM<br />
 Decreasing GPM (Water), 1.9...4.5 GPM<br />
[U]: Options, SPDT Switch, 5 Ft. Cable

Paddle Type Flow Switch<br />
Brand: KOBOLD (USA)<br />
Model: PS-5149-U<br />
[PS-5149]:<br />
Switching Tolerance: ± 15%<br />
Maximum Temperature: Max. 176 °F<br />
Media Temperature: -4...158 °F<br />
Maximum Pressure: Brass: 1/2 " = 1450 PSIG<br />
Ingress Protection: IP 65<br />
Mounting Orientation: Horizontal Flow Preferred<br />
Max Flow Rate: 5x Switching Range, Increasing<br />
Cable: PVC Jacketed<br />
Cable Length: Standard: 5 Ft. (1.5m)<br />
Approximate Switching Range*<br />
Increasing GPM water: Pipe Size 2"(18...24)<br />
Decreasing GPM water: Pipe Size 2"(16...22)<br />
Connection: 1/2" NPT<br />
Pipe size: 2", 3", 4" y 6"<br />
Material: Brass<br />
[U]: Option, SPDT Switch, 5 Ft. Cable

<div>Rotating Vane Flow Meter<br />
Brand: KOBOLD (Alemania)<br />
Model: DPM-1-5-07-G2-F300<br />
[DPM-1]:<br />
Operating principle, Rotating vane<br />
Mounting position, all directions<br />
Flow direction, in direction of the arrow<br />
max. temperature, 80 °C<br />
max. pressure, 16 bar<br />
Accuracy, +/-1,0 (2,5)%<br />
Protection, IP 65<br />
[5]: Material, st. st.<br />
[07]: Measuring range, 50-700 mL/min<br />
[G2]: Mech. connection, G 1/4 female<br />
[F300]: Evaluating Electronic, Frequency output, plug M12x1, PNP</div>

Paddle Type Flow Switch<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-11-40B-N-40-R-8<br />
[PSR-11]:<br />
Operating principle paddle<br />
Mounting position all directions<br />
incl. fitting, brass<br />
Body material, brass<br />
max. pressure, 100 bar<br />
[40B]: Measuring range/paddle, 34.1-64.2 L/min paddle: 12<br />
[N]: Connection, NPT-thread<br />
[40]: Connection, 1 1/2"<br />
[R]: Contact version, N/O<br />
[8]: Connecting cable, PVC-cable 5.0 m

Paddle Type Flow Switch<br />
Brand: KOBOLD (Alemania)<br />
Model: PSR-11-201-N-20-U-1<br />
[PSR-11]:<br />
Operating principle paddle<br />
Mounting position all directions<br />
incl. fitting, brass<br />
Body material, brass<br />
max. pressure, 100 bar<br />
[201]: Measuring range/paddle, 34.6-48.3 L/min paddle: 1<br />
[N]: Connection, NPT-thread<br />
[20]: Connection, 3/4"<br />
[U]: Contact version, SPDT<br />
[1]: Connecting cable, PVC-cable 1.5 m (standard)
