MAGNETIC PISTON PRESSURE GAUGE FOR DIFFERENTIAL<br />
PRESSURE – INDUSTRIAL VERSION<br />
Range: 0/1 bar<br />
Brand: AFRISO <br />
Housing Stainless steel 304 with rubber sealing ring at the front <br />
Measuring element See data sheet<br />
Accuracy ±3 % of full scale value (at increasing differential pressure)<br />
Connection 2 x G¼ female thread<br />
Max. static pressure: 100 bar<br />
****Include.- Model.- 38305- Plastic mounting plate for wall mounting****
<div>
<div class="gtx-trans-icon"></div>
</div>

COSASCO Corrosometer Probe Flush Element<br />
• Mounting Port 1" valve minimum (Model 3700)<br />
• Temperature Rating: 260 C<br />
• Pressure Rating: 1500 Psi<br />
• Body: Stainless Steel<br />
• Element Form: Strip Flush 8 mil thickness (4 mil useful probe life)<br />
• Element Alloy: K03005 (Pipe Grade Carbon Steel)<br />
• Order Length: 18 Inches<br />
• Safety Clamp: NOT INCLUDED

Coupon Holder Retractable system for a Flush Disc coupon..<br />
• With Stuffing Box Assy.<br />
• Length 18” according to drawing. Pressure rating 1500PSI,<br />
• Mounting 1” NPT<br />
• Requires Full port valve 1 ½” minimum with Niple reduction to 1"NPT<br />
• Safety Clamp Included<br />
• Temperature rating 260C

ICON-X COMPLETE CONFIGURATION KIT EX<br />
Brand: INOR<br />
Transmitter Configuration Kit with USB Communication<br />
PC to USB Interface USB cable type A to type B<br />
USB Interface to transmitter Changeable adapter cables<br />
Power Supply PC´s USB port, 5 VDC, 74 mA max<br />
Operation temperature 0 to 50 °C / 32 to 122 °F<br />
Storage temperature -20 to 70 °C / -4 to 158 °F<br />
Humidity (non-condensing) 0 to 90 %RH<br />
Galvanic isolation 1500 VAC<br />
System requirements<br />
Windows 32- or 64-bit edition of Windows<br />
XP (SP2+) / Vista / 7 / 8 / 8.1 / 10<br />
Free hard disk space 185 MB<br />
PC Port 1x USB 1.1 or higher port type A

EXPLOSION-PROOF DIFFERENTIAL PRESSURE SWITCH<br />
Compact, Low Cost, Explosion-proof and Weatherproof<br />
Brand: DWYER<br />
Range: 3 to 11 w.c.<br />
Service: Air and non-combustible,compatible gases.<br />
Temperature Limits: -40 to 140°F<br />
Enclosure Rating: NEMA 3 (IP54),NEMA 7 & 9.<br />
Switch Type: Single-pole double-throw (SPDT).<br />
Electrical Rating: 15 A @, 125, 250, 480 VAC, 60 Hz. Resistive 1/8 HP @125 VAC, 1/4 HP @ 250 VAC, 60 Hz.<br />
Electrical Connections: 3 screw type, common, normally open and normally closed.<br />
Process Connections: 1/8" female NPT.<br />
Mounting Orientation: Diaphragm in vertical position. <br />
Set Point Adjustment: Screw type on top of housing.<br />
Weight: 3.25 Ib (1.5 kg<br />
Agency Approvals: CE, CSA, FM, UL.
<div>
<div class="gtx-trans-icon"></div>
</div>

EXPLOSION-PROOF DIFFERENTIAL PRESSURE SWITCH<br />
Compact, Low Cost, Explosion-proof and Weatherproof<br />
Brand: DWYER<br />
Range: 0.15 to 0.50 w.c.<br />
Service: Air and non-combustible,compatible gases.<br />
Temperature Limits: -40 to 140°F<br />
Enclosure Rating: NEMA 3 (IP54),NEMA 7 & 9.<br />
Switch Type: Single-pole double-throw (SPDT).<br />
Electrical Rating: 15 A @, 125, 250, 480 VAC, 60 Hz. Resistive 1/8 HP @125 VAC, 1/4 HP @ 250 VAC, 60 Hz.<br />
Electrical Connections: 3 screw type, common, normally open and normally closed.<br />
Process Connections: 1/8" female NPT.<br />
Mounting Orientation: Diaphragm in vertical position. <br />
Set Point Adjustment: Screw type on top of housing.<br />
Weight: 3.25 Ib (1.5 kg<br />
Agency Approvals: CE, CSA, FM, UL.

Modelo:096-3349<br />
LEL Sensor Housing Assembly for Scott Freedom 6000 for combustible application

Modelo:  MULTIEXACT(O2 Purity)    <br />
•    Supply    European Power Lead(220 VAC)<br />
•    Gas Module 1:    O2 Purity(2 Decimales)<br />
o    Technology Paramagnetic<br />
o    Range 0-100%<br />
o    Accuracy (intrinsic error) <0.01% O2<br />
o    Repeatability <0.01% O2<br />
o    Zero drift/week <0.01% O2<br />
o    T90 in secs <10@200ml/min<br />
o    <br />
•    Sample System Module 1:        Flow Driven Paramagnetic    <br />
•    Sample Flowmeter:            Supply(500 ml/min)<br />
•    External Filter Module 1        Supply<br />
•    Flow Alarm:                 not required    <br />
•    Analogue Outputs:            mA Analogue Output    <br />
•    Valve Block:                not required    <br />
•    Mounting:                19" Rack Mount Ears Only

DIFFERENTIAL PRESSURE TRANSMITTER<br />
Same Size as Standard Magnehelic® Differential Pressure Gage<br />
Range: 0 to 5.00" w.c., 1243 Pa, 127.0 mm w.c., 12.43 mbar, 1.243 kPa, .180 psi.<br />
Brand: DWYER <br />
Service: Air and non-combustible, compatible gases.<br />
Wetted Materials: Consult factory.<br />
Accuracy: ±1% FS at 70°F.<br />
Stability: ±1% FS/yr.<br />
Temperature Limits: 20 to 120°F (-6.67 to 48.9°C).<br />
Pressure Limits: 10 psig (0.69 bar).<br />
Thermal Effect: ±0.055% FS/°F (0.099% FS/°C).<br />
Power Requirements: 10 to 35 VDC (2 wire).<br />
Output Signal: 4 to 20 mA.<br />
Zero and Span Adjustments: Digital push-button zero and span.<br />
Loop Resistance: DC: 0 to 1250 Ω maximum.<br />
Current Consumption: DC: 38 mA max.<br />
Electrical Connections: Screw-type terminal block.<br />
Display: 3.5 digit LCD, 0.7" H.<br />
Process Connections: 1/8" ID tubing.<br />
Mounting Orientation: Vertical.<br />
Weight: 4.8 oz (136 g).

VF-100-ST<br />
• Regulators for Non -Refillable cylinders<br />
• On/Off Knob with cylinder pressure gauge<br />
• Fits C10 Valve and refillable cylinders<br />
• Flow rate: 0.5 to 5.0 l/min - Regulable<br />
• Rango : 0 a 70 bar<br />
• Material. Stainless steel

Modelo:S4000975B<br />
Kit, Viton Tubing Refurbishment Spare

Modelo:S4000987<br />
Descripcion:Kit, Fine Filter Cap Spare

<div>TRANSMISOR DE FUJO  DE AREA VARIABLE</div>

<div>•<span> </span>Marca: AW LAKE MONITORS <br />
MODELO: R3A-6WS-02</div>

<div>•<span> </span>[R]:Estilo: Transmisor de Flujo</div>

<div>•<span> </span>[3]:Puerto / línea Rango de tamaños: 1/4" - 1/2"</div>

<div>•<span> </span>[A]:Material: Aluminio</div>

<div>•<span> </span>[6]:Rango de Presión Max:3500 PSIG</div>

<div>•<span> </span>[W]:Fluid Media: Agua y 1.0 Gravedad específica.</div>

<div>•<span> </span>[S]:Tipo de Rosca: 1/4" NPTF</div>

<div>•<span> </span>[02]:Rango de Flujo: 0.2 a 2 GPM</div>

<div>•<span> </span>Salida:4-20 mA</div>

FTII-100-516OD-M-14-DK<br />
Tubing Fitting Inox<br />
Tipo: Racor Recto (D-MT)<br />
Para Tubing de: 5/16 OD<br />
Tipo de Rosca: Macho<br />
Rosca: 1/4 NPT<br />
Marca: DK-LOK

Modelo: RTDIMAN-2-05<br />
•Marca: INTRIAL (Made in Germany)<br />
•Sensor de Temperatura PT-100 IMANTADO (200 N )simple, 3 hilos, <br />
•DIN 100 1 x Pt 100 Ohm DIN EN 60751, class A/0°C, 3-wire<br />
•Tipo superficie imantada cilíndrica diámetro 25mm, <br />
•Espesor 12.5 mm cuello de largo 50mm<br />
•Incluye 10 mts de cable fibra de vidrio malla metalica<br />
•RTDIMAN: Sensor de Temperatura tipo IMAN -50 hasta +180°C<br />
•2 = especial cable con 10 metros  3 x 0,22 mm² PTFE/acero inoxidable<br />
•05 = 05 metros de cable

•Modelo: PRO11993<br />
•Screw-in resistance thermometer<br />
•Brand:  INTRIAL (Made in Germany, special design)<br />
•2 x Pt 100 Ohm DIN EN 60751, class B, 2 x3-wire, <br />
•protective tube ø 6 mm, length 686mm<br />
•material stainless steel, <br />
•copper tip 10 mm, <br />
•spring loaded system, process<br />
•connection 1/2" NPT, thread length 14 mm,<br />
•connection head form NNA, <br />
•electrical output 1/2" NPT female,<br />
• temperature range: -50 to +400°C

AWRT20T4XXXC30XX+FA4A4+C044<br />
Acoustic Wave Remote Transducer<br />
* 20kHz Unit<br />
* Facing material: Teflon 80 C<br />
* Housing: Polypropylene<br />
* Connection: IP68 Sealed unit w/cable<br />
* Cable Length: 30m cable<br /><br />
Accessories:<br />
----------------<br />
Flange (FA4A4)<br />
============<br />
* ANSI 4"<br />
* Cone Mounted<br />
* Flange Material: Polypropylene<br />
Focaliser Cone (C044)<br />
=================<br />
* 4" Cone for 20 Khz Unit<br />
* Cone Material: Polypropylene

MANÓMETRO TIPO BOURDON<br />
Marca AFRISO(Alemania)<br />
RANGO: 0 to 70 bar/0 to 1016 psi<br />
Diámetro de Carcasa 6''(160mm)<br />
Precisión 1.6(EN 837-1/6)<br />
Temperatura Operación Max 120°C  <br />
Conexión  INFERIOR,1/2 ''NPT<br />
Material: Caja y conexión en acero inoxidable<br />
Con/sin glicerina(Especificar al ordenar, no afecta el precio)<br />
**** Incluye Certificado de calibracion****

<strong>MANÓMETRO TIPO BOURDON<br />
Marca AFRISO(Alemania)</strong><br />
RANGO: 0 to 14 bar/0 to 203 psi<br />
Diámetro de Carcasa 6''(160mm)<br />
Precisión 1.6(EN 837-1/6)<br />
Temperatura Operación Max 120°C  <br />
Conexión  INFERIOR,1/2 ''NPT<br />
Material: Caja y conexión en acero inoxidable<br />
Con/sin glicerina(Especificar al ordenar, no afecta el precio)<br />
**** Incluye Certificado de calibracion****
