GEAR PUMP, rpm 1450

GEAR PUMP<br />
Brand: RICKMEIER<br />
Dimensional drawing MZ330226-2<br />
Complete assembled and tested<br />
Suction connection acc. SAE3 (without counterflange)<br />
Pressure connection acc. SAE3 (without counterflange)<br />
Pumping medium mineral oil ISO VG 68 <br />
Fluid temperature in deg. +40 (+20...+80) <br />
Kin. viscosity in mm²/s 68 (max. 215) Oil flow approx. in dm³/min 110<br />
Inlet pressure in bar 0 (-0,4...+0,5)<br />
Outlet pressure in bar 9<br />
Speed in rpm 1450<br />
Sense of rotation (seen on shaft end) cw<br />
recommended driving power in kW 3,42 (10 bar, 215 mm²/s)<br />
Kind of shaft sealing rubber radial shaft sealing<br />
Pressure relief valve yes (with internal backflow)<br />
opening pressure (valve) in bar 10<br />
pressure range (valve) in bar 1...16<br />
Casing 5.1301 (EN-GJL-250)<br />
Gear shafts 1.7139 (16MnCrS5+FP)<br />
Elastomere NBR<br />
site conditions indoor<br />
altitude above sea level in m < 1000<br />
explosion protection (pump) without<br />
coating RM-Standard 1005-C2<br />
Referring to ISO 12944-5/C2.07-PUR Zn(PO)<br />
shade of colour RAL 7021 (black grey)<br />
Colour designation PUR COLOR PLUS<br />
base of the colour 2 K polyurethane base w. zinc phosphate<br />
Nominal dry film thickness in μm 80<br />
internal pump preservation (pump) by test fluid
