Severe Duty Magnetoresistive Sensor PPR: 4 - 50000 - 5-24V in/5-15V out 4125

•    Avtron AV5 SMARTach™ III <span style="font-size:18px;"><span class="darkgrey1"><span style="line-height:107%;font-family:Calibri, sans-serif;">Severe Duty Magnetoresistive Sensor </span></span></span><br />
•    Operating Power: Volts: 5 - 24 VDC*<br />
•    Current: 100mA nom, no load<br />
•    Output Format: A Quad B with Marker (A,A–, B,B–, Z,Z–)<br />
•    Second Isolated Output: Optional<br />
•    Frequency Range: @5V, @1m cable, 250 kHz Max<br />
•    @24V, @300m cable, #8 output, 45 kHz Max<br />
•    Maximum Cable Length: 1000'<br />
•    PPR: 4 - 50000***<br />
•    Speed: 5400 RPM Max****<br />
•    Electronics: Fully Encapsulated, IP67**<br />
•    Temperature: -40° to 120°C (150°C rotor)^<br />
•    Vibration: 18 g’s<br />
•    Shock: 1 meter drop test<br />
•    Chemical: Polyurethane enamel paint protects against salt spray, mild acids, and bases.<br />
•    Weight: 2 - 3 lbs [0.9 - 1.36 kg] (will vary by connector options<br />
•    AV5:    Model<br />
•    8:         Line Driver( 5-24V in/5-15V out 4125)<br />
•    J:       PPR (960)<br />
•    T:         Connector Option()<br />
•    000:      Modifications (none)
