EPS Electromagnetic Flow Meter, DN400 PN16 Form B1 DIN EN 1092-1

EPS Electromagnetic Flow Meter<br />
Brand: KOBOLD <br />
Model:  EPS-H-376B-1-S-S-1-0 <br />
[H] Material Lining; Hard Rubber (Ebonit)<br />
Electrodes; Standard 2x Measuring- + 2x Groundelectrodes<br />
Process-Temperature; 0°C…+95°C<br />
[376B] Process connection; DN400 PN16 Form B1 DIN EN 1092-1<br />
Max. measuring range (Water 20°C, 1 mPas); 4191 m³/h<br />
Installation length; 600 mm<br />
[1] Material Process connection; Flange steel painted<br />
[S] Material electrodes; st.st. 1.4571 (316 -TI) <br />
[S] Earthing electrode; st.st. 1.4571 (316 TI)<br />
[1] Transmitter mounting; Integrated transmitter<br />
Protection class, sensor; IP67 <br />
[0] Certificates; w/o<br /><br />
Model: UMF2-A-1-1-G-0BK<br />
[UMF2]:Transmitter<br />
[A]: Mounting, Integrated transmitter IP 67 standard<br />
Thread - electrical connection, ½" NPT (f)<br />
[1]: Display and control unit, integrated<br />
[1]: Power supply, 230V AC (+10%, -15%), 50/60Hz<br />
[G]: Output Signal:<br />
current output: 1x 0/4-20 mA c/w HART protocoll<br />
pulse output: passive Um=24 VDC<br />
status output: passive Um=24 VDC<br />
[0BK]: Design, Kobold
