TRANSMISOR/ INDICADOR DE PRESION DIFERENCIAL, 0-20" w.c, 11 psi (75.8 kPa)

<p class="MsoNormal"></p>

<p></p>
<span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">MAGNEHELIC® DIFFERENTIAL PRESSURE INDICATING TRANSMITTER</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Brand: DWYER</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Range: 0-20" w.c., max. pressure 11 psi (75.8 kPa)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">±0.5% electrical accuracy, ±2% mechanical accuracy.</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">SPECIFICATIONS GAGE SPECIFICATIONS</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Service: Air and non-combustible, compatible gases</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Accuracy: See chart. Stability: ±1% FS/yr.</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Pressure Limits: See chart</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Temperature Limits: 20 to 120°F (-6.67 to 48.9°C).</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Process Connections: 1/8˝ female NPT</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Size: 4˝ (101.6 mm) dial face, 5˝ (127 mm) OD x 2-11/16˝ (68.3 mm)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Weight: 1 lb, 12.6 oz (811 g)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Agency Approvals: CE.</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">TRANSMITTER SPECIFICATIONS</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Temperature Limits: 20 to 120°F (-6.67 to 48.9°C)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Compensated Temperature Range: 32 to 120°F (0 to 48.9°C)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Thermal Effect: ±0.025% FS/°F (0.045% FS/°C)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Power Requirements: 10-35 VDC (2-wire)</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Output Signal: 4 to 20 mA.</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Zero and Span Adjustments: Protected potentiometers</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Loop Resistance: DC; 0-1250 Ω max</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Current Consumption: DC; 38 mA max</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Electrical Connections: Screw terminal block</span><br /><span style="font-family:'Arial Narrow', sans-serif;font-size:10pt;">Mounting Orientation: Diaphragm in vertical position</span>
